Power Kit STEVAL-STMicroelectronics ISA081V1
Power Kit STEVAL-ISA081V1a SMPS (switched mode power supply - switched mode power supply) output 12 W development kit and demo preparation with the export feature is SMPs an isolated wide input voltage range.
STEVAL-using the 12 V nominal output voltage produces a primary Editing isa081v1 SMPs, and high voltage monolithic MOSFET and a PWM controller is based on combining viper26 converters in a single package.
Power Kit STEVAL-ISA081V1 general characteristics
- Vin: 85 ~ 305 Vrms / f: 45 ~ 66 Hz
- V cikisi1 : 12 VDC ± 10%, 1 (at 3.3 V not installed)
- cikisi2 V : 3.3 VDC ± 4%, 100 MA
- maximum total output current: 1 a
- Standby <120 mW, 230 VAC'de
- short circuit: protected
- PCB type and size: single-sided FR4 35m 35, 32 x 90 mm
- Insulation: insulated 4 kV / 8 mm
- EMI: According to en55022 Class A
- RoHS compliant,
click here to get detailed information about the product.
