TPM 2.0 Security Module – SPI/I2C Security Chip ST33KTPM2XI2C

STMicroelectronics TPM 2.0 Security Module – SPI/I2C ST33KTPM2XI2C the security chip

STMicroelectronics ST33KTPM2XI2C brand design, embedded systems are designed to maintain the highest level of security and data integrity. Flash-based architecture, in addition to the features at the hardware level TPM traditional intrusion prevention, and self-rescue capability. With support for both SPI and I2C interface is easily integrated into systems. Strong cryptographic algorithms, certification, compliance and environmental durability with industrial, institutional, and is one of the ideal choice for mobile security solutions.

ST33KTPM2XI2C what is it?

ST33KTPM2XI2C product complies with the TPM 2.0 standard, running, a flash memory-based integrated security. At the hardware level of data protection, random number generation, cryptographic operations such as the processing device performs at a high level of security and authentication capabilities. Wide operating temperature range, thanks to the integrated active protection mechanisms against various types of attacks and error correction codes, can be used with confidence in demanding industrial applications. Prominent st33ktpm2xi2c versatile use in different areas to meet the needs of designers who work most effectively.

ST33KTPM2XI2C functions which come to the fore with?

ST33KTPM2XI2C, in order to ensure the security of the system both hardware and software in layers of strong features. Device fault-tolerant against cuts that may occur in the process of the firmware update installer self-recovery feature provides. Fast data transfer via the SPI and I2C interfaces are both supported. High frequency allows you to work on the structure, which establishes secure connections without sacrificing performance. TCG FIPS 140-3 test suites in terms of features and ST33KTPM2XI2C Common Criteria EAL4+ complies with international safety standard such as.

The technical specifications of the product ST33KTPM2XI2C

ST33KTPM2XI2C, that offers high level security at the level of both hardware and software features. In this way, the exhibits stable performance during applications. ST33KTPM2XI2C technical specifications are as follows:

• a working model fully compliant with the standard TPM 2.0, TCG platform TPM profile (PTP) supports version 1.05.
• Due to the structure of running on flash memory, you can save yourself during firmware updates.
• 66 MHz SPI interface I2C interface allows you to transfer data to 1 Mbps.
• Operating between 1.8 V and 3.3 V wide supply voltage range is compatible with different systems.
• The product * Operating Temperature -40°C to +105°C range. Thus, even under harsh conditions works in a safe manner.
• Hardware-based error correction code with the support maintains data integrity.
• RSA, ECC, AES, SHA-1/2/3, such as the current HMAC cryptographic algorithms in hardware is supported.
• For both deterministic random number generation (DRBG) both true random (TRNG) generator is integrated.
• Active shield against physical attacks, environmental monitoring, and advanced security protection measures, such as error injection are available.
• Common Criteria EAL4+ and FIPS 140-3 as a global security certification is designed for your goals.
• RSA2048, ECC P-256 and ECC P-384-based three pre-installed comes with the key and certificate check.
• Resistance to electrostatic discharge 4 KV HBM is equal to the level of.
• 5 x 5 x 0.55 mm in the size of the package ECOPACK2 thanks to small areas can be easily integrated.
• 10/11 Microsoft Windows, Linux, and Intel® vPro® platforms fully compatible with the works.
• Open-source TCG software stack developer with TPM 2.0 friendly design.

What are the areas of use ST33KTPM2XI2C?

ST33KTPM2XI2C has a fairly wide range in terms of use. It is often desirable in desktop and notebook computer systems. On the basis of server and embedded systems, will benefit from this component. In addition, it plays an effective role in IoT devices known as the Internet of objects. Enterprise data encryption, device authentication, secure initialization, such as remote management of security issues in projects that are at the forefront widely preferred. Critical infrastructure security solutions in areas such as industrial automation systems and intelligent equipment ST33KTPM2XI2C safe it is distinguished by its structure.

ST33KTPM2XI2C what is the price?

ST33KTPM2XI2C price, top-level safety standards when considering quite an advantage. The model developed fairly balanced in terms of performance, the price of a product. Prices, order quantity, packaging type of supply can vary depending on factors such as duration. You ST33KTPM2XI2C Empa product at advantageous prices affordable through the store can be obtained. Empa Electronics offers technical support privileges you can carry out the process safely and fast delivery. Among the models you like from the online store and purchase products you can easily make st33ktpm2xi2c.
