Cortex-M4/M0+ Low Power Consumption MCU STM32WB35CC

STMicroelectronics Cortex-M4/M0+ low-power MCU STM32WB35CC

STMicroelectronics multi-protocol wireless communication solutions supporting STM32WB35CC, combines high performance with low power consumption. 2.4 GHz radio frequency over various wireless protocols has this model, which is ideal for IoT networks from application to a wide range of smart devices. The low-energy modes, and powerful computing architecture forms the foundation of advanced security equipment and system design. STM32WB35CC optimally meets the requirements of amateur and professional designers from different sectors

STM32WB35CC what is it?

STM32WB35CC product, Arm® Cortex®-M4 based 32-bit architecture, with multi-protocol microcontroller design. Creates strong links with wireless communication capabilities with peripherals. Processor frequency 64 MHz, FPU and DSP instructions support equipped with an integrated, component, digital processing, wireless communication will fulfill the tasks successfully. The device Bluetooth® comes integrated with an RF transceiver in accordance with the protocol and IEEE 802.15.4 5.4. In addition, 512 KB flash and 96 KB SRAM memory capacity, the application allows you to run code synchronously and wireless stacks. During applications with low energy consumption energy efficiency.

The versatile features of the product STM32WB35CC

STM32WB35CC, versatile forms the basis for many applications with wireless communication capabilities. Cortex®-M0+ processor, which has an auxiliary product, real-time radio operations can be integrated. Radio operations in a manner independent of application code in parallel and allows you to work with. In IPCC integrated with the system performs fast data transfer between the two processors. Bluetooth® ad extensions caching GATT, EATT ble supports features such as new generation. Thus the modern IoT and mobile solutions is located in the advanced connection. STM32WB35CC has a very wide application area in terms of features.

The technical features of the model STM32WB35CC

STM32WB35CC hardware features of the model, creates a strong foundation for wireless applications. STM32WB35CC technical specifications, can be explained in the following way:

• ARM® Cortex®-M4 core, 64 MHz CPU, FPU and DSP instruction support high-performance data processing exhibits.
• In the 2.4 GHz frequency Bluetooth® 5.4, IEEE 802.15.4 Zigbee® RF transceiver includes 1.3 and thread according to protocol. Thus, radio frequency support.
• NA 13 off mode, standby, halt modes, as well as ultra-low energy profile. Works with low energy consumption during applications.
• 512 KB flash and 96 KB SRAM, thanks to the ample storage space it creates.
• ARM® Cortex®-M0+ wireless utility, kernel, radio is designed to manage stacks.
• 12-bit ADC and two ultra-low-power comparator with precision analog measurements.
• Model with improved connections, creates a connection with the peripheral interface qspi versatile. It is preferred in many applications with versatile connectivity options.
• Hardware key customer management, memory protection PCROP, “Secure Firmware Installation” with extra safety features, such as builds.
• 16-bit and 32-bit timers, and timer low power RTC with flexible solutions to control the timing is suitable.
• Touch sensor for up to 18 interface designs-assisted “Touch sensing controller” includes the system.
• Product 7x7 mm dimensions. Small package suitable for applications with a compact design.
• Microcontroller -40°C to +105°C temperature range supports safe operation. This feature is highly resistant against challenging working conditions.
• Operates with a supply voltage 1.71 3.6 V model.

STM32WB35CC what are the uses?

STM32WB35CC is very common in the use of applications in many sectors. In general, low-power and wireless connectivity ideal for systems that require solutions. Smart home devices, wearable technology products, wireless sensor networks, smart meter systems and remote monitoring applications, the most widely used. 5.4 with BLE Zigbee® and thread support, helps to establish secure communication between devices. In addition, OTA update capability, long-term field device management makes it easy. STM32WB35CC, medical equipment, industrial exhibits reliable performance monitoring systems in many industries.

Price STM32WB35CC

multiprotocol wireless connection with the properties STM32WB35CC is a model that attracts attention with price. Product price, order quantity, and availability may vary depending on the type of package. Empa designers STM32WB35CC affordable model can reach through the store. Safe addresses for shopping, which was one of the most important Empa Store your projects with a wide variety of products reliable solution partner. And you also purchase products through the online store, you can perform various electronic STM32WB35CC.
